Specifications:



Light source: 100W LED white light module (new generation packaging technology, perfect concentrating, super bright brightness)

Maximum power: 200W

Power supply: Wide voltage input switching power supply 100V-240V 50-60Hz

Color temperature: 6500K

Lamp life: 50000 hours



Control mode: DMX512 signal input, automatic operation

Channel mode: 16CH/20CH

X/Y scan: horizontal 540°, vertical: 270°

Color: 13 color patches + pure white light, and an independent 6 color palette, can achieve the pattern rainbow effect

Fixed pattern: 11 fixed patterns + white light, dithering effect



Atomizing mirror: atomizing soft mirror

Dimming: 0-100% linear dimming

Strobe: Synchronous pulse strobe, random pulse strobe

Prism disk: double prism effect, one 16 prism, one 8 prism, two-way rotation effect

Beam angle: 2°

Focusing: the pattern can be adjusted freely



Display: color LCD display, Chinese and English display, reverse display

The system has an RDM function to remotely modify the address code.

Efficient heat pipe cooling system, no risk of lamp damage



Protection level: IP20
