Technology Parameter

Lamp : YODN

Voltage : 110W~240V/50-60Hz

Ballast: Electronic Ballast

Average Lifespan: 2200Hrs

Power consumption: 470W

Lens : high precision optical lens

Color wheel: 13 dichroic filters + white

Rotating Gobo Wheel, with 9 bidirectional and indexable gobos

Static Gobo wheel with 14 fixed gobos, at variable rotation

Prism 1: 8-facet circular prism rotating in both directions at different speeds

Prism 2: 6-facet linear prism rotating in both directions at different speeds

Zoom: parallel beam angel 2.5°-20° change

Wash effect : adjustable Wash effects angle

Focus: linear adjustment

Dimmer : 0-100% linear adjustment

Strobe : Double lens strobe (0.5-9 times/ second)

Pan/Tilt : X axis 540° Y axis 270°automatically accurate positioning

Fixation option: Pan/Tilt-lock mechanism

Control mode : Standard DMX512, Automatic and Master/ slave mode

Channel : 16 CHs / 24 CHs

Controller can open the lamp and reset, including delaying function

Weight : 21kG

Dimension: 386 (L) X 365 (W) X 589 (H) mm
